Laboratory Freezer ZLN 85
Laboratory Freezer ZLN 85 - Image 2
Laboratory Freezer ZLN 85 - Image 3
Laboratory Freezer ZLN 85 - Image 4

Laboratory Freezer ZLN 85

POL-EKO Laboratory Freezer ZLN 85
The ZLN 85 is a professional 85-liter laboratory freezer providing a reliable temperature range of 2$-25^{circ}C$ to 3$0^{circ}C$.4 Utilizing natural air convection to ensure a stable environment without the risk of sample cross-contamination from high-speed fans, it is ideal for long-term storage in clinical and research labs.5 Managed by the Smart 4.3-inch touchscreen (or the advanced 7-inch Smart PRO), it features integrated data logging via USB/LAN, an “Alarm Bar” for instant status updates, and a robust acid-proof stainless steel interior.6 Its secure door lock and open-door alarm provide critical protection for sensitive temperature-dependent assets.

Add to WishlistRemove from Wishlist
Add to Wishlist
SKU: ZLN 85 Categories: , Brand: Product ID: 21681

Description

The POL-EKO ZLN 85 is engineered for laboratories that need high-performance freezing capabilities within a small footprint. Its 85-liter chamber (with a 73-liter working capacity) is perfectly sized for under-bench placement or small workspaces.8 Unlike larger industrial units, the ZLN 85 uses Natural Convection, which relies on gravity-driven air movement.9 This is particularly beneficial for storing fine powders or delicate samples that might be sensitive to the air turbulence caused by fans.+1Intelligent Monitoring and GLP Compliance:The ZLN 85 is available with two controller options to suit different regulatory needs:10Smart Controller (Standard): A 4.3-inch color touchscreen that supports up to 5 user programs.11 It includes a built-in event registry and data logging, accessible via USB and LAN ports.Smart PRO Controller (Optional): Designed for highly regulated environments (e.g., 21 CFR Part 11). It features a larger 7-inch screen, Wi-Fi connectivity, multi-level user management (Admin/User), and expanded memory for up to 40 programs and detailed audit trails.12The Alarm Bar: Both models feature a high-visibility light strip that allows staff to monitor the freezer’s status from a distance?green for stable operation and red for any temperature excursions or alarms.13Industrial Build for Sample Integrity:The interior is crafted from acid-proof stainless steel (DIN 1.4301), ensuring maximum resistance to chemicals and easy decontamination.14 The unit comes standard with two stainless steel wire shelves (expandable to four) and includes a 15$emptyset$20 mm access port on the left wall for external temperature validation probes.16 For security, the solid door is equipped with a physical key lock to prevent unauthorized access to sensitive samples.17+1Primary Applications:Biological Research: Storage of enzymes, DNA/RNA samples, and proteins.18Clinical Labs: Preservation of reagents and medical samples.Chemical Storage: Safe keeping of temperature-sensitive volatile chemicals.Pharma QC: Stability testing and long-term storage of drug components.

Datasheet

Download ZLN 85 Smart Datasheet

Download ZLN 85 Smart PRO Datasheet

Specifications

POL-EKO Laboratory Freezer ZLN 85 Full Technical Specifications

The ZLN 85 is a natural air convection freezer designed for precise temperature control and durable sample storage. Below is the complete list of specifications in a copy-paste friendly format.

Physical & Capacity Data

  • Chamber Capacity (Gross): 85 Liters

  • Working Capacity: 73 Liters

  • External Width: 610 mm

  • External Height: 920 mm

  • External Depth: 650 mm (excludes 50 mm power cable)

  • Internal Width: 380 mm (max 420 mm)

  • Internal Height: 590 mm

  • Internal Depth: 400 mm (bottom step depth is 230 mm)

  • Net Weight: 60 – 62 kg

  • Standard Shelves: 2 (Stainless steel wire INOX)

  • Maximum Shelves: 4

  • Max Shelf Workload: 10 kg

  • Max Unit Workload: 30 kg

  • Access Port: Ø20 mm (located on the left wall)

Performance & Cooling

  • Temperature Range: $-25°C$ to $0°C$

  • Temperature Resolution: $0.1°C$

  • Temperature Fluctuation (at -20°C): $pm 0.5°C$

  • Temperature Variation (at -20°C): $pm 2.0°C$

  • Air Convection: Natural (Gravity)

  • Defrosting: Manual

  • Refrigerant: R290 (GWP = 3) or R455A (GWP = 146) depending on production year

  • Insulation Type: Polyurethane foam

Electrical & Build

  • Voltage: 230V, 50/60 Hz

  • Nominal Power: 200 W

  • Door Type: Solid, right-hinged (reversible as an option), lockable

  • Interior Material (P version): Acid-proof stainless steel to DIN 1.4301

  • Housing Material: Powder-coated galvanized sheet (Stainless steel polished version available)

  • Warranty: 24 months

Controller Variant Comparison

Smart Controller (Standard)

  • Display: 4.3″ Full-color touch screen

  • Connectivity: LAN, USB ports for data transfer

  • Internal Memory: Storage for 5 programs (up to 6 segments each)

  • Security: Class 2.0 (DIN 12880) temperature protection

  • Data Log: 10,000 data points (stored for up to 6 months)

Smart PRO Controller (Advanced)

  • Display: 7.0″ Full-color touch screen

  • Connectivity: LAN, USB, and integrated WiFi

  • Internal Memory: Storage for 40 programs (up to 100 segments each)

  • User Accounts: Up to 5 user accounts (Admin / Super-Admin / User)

  • Security: Class 3.2 (DIN 12880) temperature protection

  • Software: Includes LabDesk software for remote management and data export

  • Data Log: 10,000 data points (stored for up to 12 months)
