Description
The SciAps X-550 is the premier choice for high-speed alloy analysis and non-destructive testing. Engineered to be the lightest and fastest handheld XRF on the market, it delivers grade identification in under one second. It is specifically optimized for low atomic number elements like magnesium, aluminum, silicon, phosphorus, and sulfur, making it the “gold standard” for aluminum sorting and sulfidic corrosion testing.
Its sleek, tapered design allows for easy access into tight welds and corners, while the internal heat-sinking technology enables continuous operation even in high-temperature environments. With its app-based interface and hot-swappable battery system, the X-550 is designed for maximum uptime and field efficiency.
Specifications
Below is the comprehensive technical specification list for the SciAps X-550 and X-555 handheld XRF analyzers.
Core Analytical Hardware
| Feature |
SciAps X-550 |
SciAps X-555 |
| Excitation Source |
5W X-ray tube (Max 50 kV / 200 µA) |
5W X-ray tube (Max 55 kV / 200 µA) |
| Tube Anode |
Rhodium (Alloy) or Gold (Soil/Geo) |
Gold (Au) |
| Detector |
20 mm² Silicon Drift Detector (SDD) |
50 mm² Large Area SDD |
| Resolution |
<140 eV FWHM at 5.95 Mn K-alpha |
<140 eV FWHM at 5.95 Mn K-alpha |
| Pulse Processor |
12-bit or 14-bit (80 MSPS) |
12-bit (80 MSPS) |
| X-Ray Filtering |
6-position automated filter wheel |
6-position automated filter wheel |
System Architecture & Data
-
Processor: 1.2 GHz Quad-core ARM Cortex-A53 (64/32-bit).
-
Operating System: Android-based platform with app-driven interface.
-
Memory: 2 GB LPDDR3 RAM.
-
Storage: 16 GB eMMC internal storage.
-
Multi-Channel Analyzer: 8K channel MCA.
-
Digital Filtering: FPGA-based (20 ns – 24 µs peaking time).
-
Connectivity: Integrated Wi-Fi, Bluetooth, USB, and GPS-capable.
-
Imaging: * Internal high-resolution camera for sample targeting.
Physical & Environmental
-
Weight: 2.98 lbs (1.35 kg) including the battery.
-
Dimensions: 8.5 x 9.5 x 2.4 inches.
-
Display: 2.7-inch color capacitive touchscreen (rear-facing).
-
Power Source: Rechargeable Li-ion battery.
-
Power Management: 60-second hot-swap capability.
-
Housing: Aerospace-grade aluminum for durability and heat sinking.
-
Operational Temp: 10°F to 130°F (-12°C to 54°C) at a 25% duty cycle.
Analytical Range & Applications
-
Standard Elements: 32 elements (Magnesium to Uranium).
-
X-550 Primary Apps: Alloy ID (fastest for Mg, Al, Si, P, S), Sulfidic Corrosion, Residuals (API 751), Lead Paint (HUD PCS compliant).
-
X-555 Primary Apps: Rare Earth Elements (REEs), Mining/Geochem (extra-low detection limits for Cd, Ag, Sn, Sb, Ba), Soil.
-
Calibration: Fundamental Parameters (standard); Compton Normalization and Empirical (optional).
Compliance & Security
-
Regulatory: CE, RoHS, USFDA registered, Canada RED Act compliant.
-
Security: Password-protected multi-user support with configurable access.
Meta Descriptions
-
SciAps X-550: “The industry’s fastest and lightest handheld XRF for alloy analysis and NDT. Optimized for sub-second grade ID and low Si/Mg performance.”
-
SciAps X-555: “The world’s only 55 kV handheld XRF analyzer. Engineered for elite sensitivity in Rare Earth Element detection and heavy metal analysis.”
