MS6-Pro LCD Digital Magnetic Stirrer Specifications
The MS6-Pro is a high-performance digital magnetic stirrer designed for precise mixing of liquids. It features an advanced LCD display and a compact, space-saving design suitable for various laboratory environments.
Technical Parameters
-
Stirring Speed Range: 100 – 1500 RPM
-
Speed Display Resolution: ±1 RPM
-
Max. Stirring Quantity ($H_{2}O$): 20 Liters
-
Max. Magnetic Bar Length: 80 mm
-
Motor Type: Brushless DC motor
-
Motor Input Power: 18 W
-
Motor Output Power: 10 W
-
Power Consumption: 30 W
Physical and Material Data
-
Work Plate Dimension: 135 mm
-
Work Plate Material: Stainless steel with ceramic coating
-
Unit Dimensions: 160 x 280 x 85 mm
-
Unit Weight: 2.8 kg
-
Protection Class: IP42
-
Voltage and Frequency: 100-120V / 200-240V, 50/60 Hz
-
Permissible Ambient Temperature: 5 – 40°C
-
Permissible Relative Humidity: 80% RH
Functional and Safety Features
-
LCD Digital Display: High-resolution screen provides clear and real-time monitoring of stirring speeds.
-
Precise Speed Control: Microprocessor-controlled technology ensures consistent stirring speed even with changes in sample viscosity.
-
Ceramic Coated Plate: The stainless steel work plate is coated with ceramic to provide excellent chemical resistance and durability.
-
Maintenance-Free Drive: Equipped with a brushless DC motor for quiet operation and a long service life without internal maintenance.
-
Stable Design: The low-profile housing and non-slip feet provide stability during high-speed stirring operations.
