Laboratory Sterilizer SRW 1000

POL-EKO Laboratory Sterilizer SRW 1000 The SRW 1000 is a high-capacity 1005-liter laboratory sterilizer engineered for rapid, large-scale hot-air sterilization. Featuring high-efficiency forced air convection for superior temperature uniformity, it operates across a wide range from ambient +5?C to +250?C. Managed by the Smart 4.3-inch touchscreen (or the 7-inch Smart PRO), it features an automatic door-locking safety system, pre-installed sterilization cycles (including dedicated mask modes), and a total unit workload capacity of 300 kg. Its acid-proof stainless steel interior and audit-ready data logging via USB/LAN make it the definitive choice for the most demanding sterile processing environments.

SKU: SRW 1000 Categories: , Brand: Product ID: 21652

Description

The POL-EKO SRW 1000 represents the pinnacle of hot-air sterilization technology. Designed for high-throughput facilities, its 1005-liter internal capacity allows for the organization of up to 22 shelves, providing unprecedented flexibility for sterilizing anything from heavy surgical containers to large quantities of laboratory glassware.5 To ensure consistency in such a massive space, the Forced Air (W) system employs powerful fan-assisted circulation (adjustable 0?100%) to eliminate cold spots and maintain a strictly uniform temperature profile throughout the chamber.6+1Safety and Advanced Control Systems:The SRW 1000 prioritizes the protection of the operator and the load through a sophisticated electronic suite:Automatic Security: The unit features a motorized door lock that engages the second a sterilization program begins.7 It will not release until the process is safely completed and the internal temperature has dropped to a secure level, preventing accidental burns.Intelligent Controller Options: * Smart: Features a 4.3-inch touchscreen, 5 user programs, and internal data logging.8Smart PRO: Offers a 7-inch touchscreen, 40 user programs, Wi-Fi connectivity, and 21 CFR Part 11 readiness.Specialized Protocols: Standardly equipped with pre-loaded programs for 9$160^{circ}C$, 10$180^{circ}C$, and 11$200^{circ}C$ cycles, as well as a dedicated mask and document disinfection mode.12Air Management: An automatic 13$emptyset 60 text{ mm}$ air-flap closes during sterilization to seal the chamber and opens during cooling to speed up cycle completion.14Industrial-Grade Durability:The interior is made of acid-proof stainless steel (DIN 1.4301), while the heavy-duty housing is available in powder-coated steel or a “linen finish” stainless steel (IG version).15 Given its size, the unit is standardly equipped with heavy-duty castors for facility mobility and a reinforced structure capable of handling a massive total workload of 300 kg (with individual reinforced shelves rated for 100 kg).Primary Applications:Centralized Hospital Sterilization: Processing high volumes of surgical and orthopedic sets.Large-Scale Pharma/Biotech: Decontaminating production equipment and large batches of vials.Mass Crisis Response: High-volume disinfection of personal protective equipment (PPE).16Industrial Research: Accelerated thermal aging and sterilization of heavy-duty parts.

Specifications

POL-EKO Laboratory Sterilizer SRW 1000 Full Specifications

The SRW 1000 is the largest model in the SR series, offering a massive 1005-liter capacity. It utilizes forced air convection to ensure rapid heating and high temperature uniformity throughout its oversized chamber. This unit is designed for industrial-scale dry heat sterilization and high-volume drying of laboratory glassware and instruments.




Physical & Capacity Data

  • Chamber Capacity (Gross): 1005 Liters


  • Working Capacity: 1005 Liters


  • External Width: 1260 mm


  • External Height: 2000 mm


  • External Depth: 880 mm (excludes 50 mm power cable)

  • Internal Width: 1040 mm


  • Internal Height: 1610 mm


  • Internal Depth: 600 mm


  • Net Weight: 330 kg to 370 kg (depending on build)


  • Standard Shelves: 6 (Stainless steel wire INOX)


  • Maximum Shelves: 22

  • Max Shelf Workload: 25 kg (Reinforced shelf option: 100 kg)


  • Max Unit Workload: 300 kg

  • Access Port: Ø30 mm (standard on the left wall)


  • Door Type: Double solid doors (Viewing windows optional)


  • Mobility: Heavy-duty castors included as standard

Performance & Heating

  • Temperature Range: +5°C above ambient to +250°C


  • Temperature Resolution: every 0.1°C


  • Temperature Fluctuation (at 105°C): ± 0.6°C


  • Temperature Variation (at 105°C): ± 3.0°C


  • Air Convection: Forced (Fan speed adjustable 10% to 100%)

  • Sterilization Cycle Features: Automatic door lock during cycles; automatic air-flap closure upon program start.



Electrical & Build

  • Voltage: 400V 3/N (50/60 Hz)


  • Nominal Power: 5500 W


  • Interior Material: Acid-proof stainless steel (DIN 1.4301)

  • Housing Material: Powder-coated sheet (Standard) or Stainless steel linen finish (IG versions)


  • Warranty: 24 months



Controller Features (Smart)

The SRW 1000 is equipped with the Smart controller, specifically designed to manage the complexities of a large-scale sterilization chamber.


  • Display: 4.3″ Full-color touch screen (responsive to latex/laboratory gloves).


  • Programs: Memory for 3 factory sterilization programs (including mask sterilization) and 5 user-definable programs.


  • Connectivity: LAN and USB ports for comprehensive data transfer and validation reporting.


  • Security: Class 2.0 (DIN 12880) temperature protection as standard (Class 3.1 optional).


  • Event Logging: Internal memory stores up to 10,000 data records for process control and validation.
