Description
Designed for demanding laboratory environments, the CHL 500 includes a microprocessor-controlled Smart or Smart PRO touchscreen controller that enables intuitive programming, precise temperature management, and advanced data handling. Connectivity options include LAN and USB ports, with the Smart PRO version adding Wi-Fi communication and expanded data logging capabilities for compliance and traceability.
Standard features such as internal LED lighting, an open-door alarm, a door lock for security, and a 30 mm external sensor access port support both convenience and operational control. The refrigerator comes with stainless-steel wire shelves and offers flexibility with optional accessories like reinforced shelves, glass doors, drawers, internal sockets, castors, and more to tailor the unit to specific laboratory workflows.
Available in Comfort and Premium variants, the CHL 500?s robust construction, advanced control options, and reliable performance make it suitable for research laboratories, hospitals, pharmaceutical facilities, and quality-assurance settings where precise temperature control and documentation are essential.
Specifications
POL-EKO Laboratory Refrigerator CHL 500 Full Specifications
The CHL 500 is a professional single-chamber laboratory refrigerator with a 500-liter capacity. It is designed for the high-volume storage of medicines, vaccines, and laboratory reagents. This model features a monoblock cooling system and forced air convection to ensure rapid temperature recovery and uniform cooling even when the chamber is fully loaded.
Physical & Capacity Data
-
Chamber Capacity (Gross): 500 Liters
-
Working Capacity: 447 Liters
-
External Width: 620 mm
-
External Height: 1940 mm
-
External Depth: 810 mm (excludes 50 mm power cable)
-
Internal Width: 500 mm
-
Internal Height: 1510 mm
-
Internal Depth: 660 mm
-
Net Weight: 105 kg
-
Standard Shelves: 3 (Stainless steel wire INOX)
-
Maximum Shelves: 11
-
Max Shelf Workload: 30 kg
-
Max Unit Workload: 100 kg
-
Access Port: Ø30 mm (located on the left wall)
-
Door Type: Single solid door (External glass door or internal glass doors optional)
-
Mobility: Castors included as standard for easy positioning
Performance & Cooling
-
Temperature Range: 0°C to +15°C
-
Temperature Resolution: every 0.1°C
-
Temperature Fluctuation (at 4°C): ± 0.4°C
-
Temperature Variation (at 4°C): ± 0.7°C
-
Air Convection: Forced (Fan-assisted)
-
Defrosting: Automatic
Electrical & Build
-
Voltage: 230V, 50/60 Hz
-
Nominal Power: 450 W
-
Refrigerant: R290 (GWP=3)
-
Interior Material: Available in Stainless steel (DIN 1.4016) or Acid-proof stainless steel (DIN 1.4301)
-
Housing Material: Powder-coated sheet or polished stainless steel
-
Warranty: 24 months
Controller Variant Features
Smart Controller (Standard)
-
Display: 4.3″ Full-color touch screen
-
Connectivity: LAN, USB ports
-
Programs: 5 user programs (6 segments each)
-
Security: Class 1.0 (DIN 12880) temperature protection
Smart PRO Controller (Advanced)
-
Display: 7.0″ Full-color touch screen
-
Connectivity: LAN, USB, and integrated WiFi
-
Programs: 40 user programs (100 segments each)
-
User Accounts: Up to 5 user accounts (Admin/Super-Admin)
-
Security: Class 3.2 (DIN 12880) temperature protection
-
Data Recording: Tabular and graphic data view (12 months storage)
