F100/250/500/1000/2000 LCD Digital Magnetic Stirrer Heating Mantle

The F-Series LCD Digital Magnetic Stirrer Heating Mantle provides precise heating and stirring for round-bottom flasks. Equipped with an LCD display, digital temperature control, and durable mantle insulation, it is ideal for laboratory heating applications requiring accuracy, safety, and reliability.

SKU: MS-H380 Categories: , , Brand: Product ID: 21710

Description

The F-Series LCD Digital Magnetic Stirrer Heating Mantle is designed for efficient and uniform heating of round-bottom flasks in laboratory environments. Available in 100 ml, 250 ml, 500 ml, 1000 ml, and 2000 ml capacities, it supports a wide range of chemical, pharmaceutical, and research applications.

The unit features an intuitive LCD display that allows real-time monitoring and precise adjustment of temperature and stirring speed. The built-in magnetic stirring system ensures consistent mixing while the heating mantle delivers even heat distribution, minimizing thermal gradients and reducing the risk of sample degradation.

Constructed with high-quality insulation materials, the heating mantle enhances thermal efficiency and user safety during extended operation. Its robust design, combined with digital control and over-temperature protection, makes the F-Series a dependable solution for routine laboratory heating and stirring tasks.

Specifications

Specifications — F-Series LCD Digital Magnetic Stirrer Heating Mantle

General

  • Model Options: F100 / F250 / F500 / F1000 / F2000

  • Display: LCD digital display

  • Housing Material: Chemical-resistant coated steel

  • Heating Mantle Material: Fiberglass heating element with heat-resistant insulation

  • Power Supply: AC 220–240 V, 50/60 Hz (custom voltage available)

  • Temperature Unit: °C


Heating

  • Temperature Range: Ambient +5°C to 380°C

  • Temperature Accuracy: ±1°C

  • Temperature Resolution: 1°C

  • Max Heating Power (approx):

    • F100: 150 W

    • F250: 200 W

    • F500: 300 W

    • F1000: 400 W

    • F2000: 500 W

  • Over-temperature Protection: Yes


Stirring

  • Stirring Type: Magnetic stirring

  • Stirring Speed Range: 100–2000 rpm

  • Stirring Speed Resolution: 10 rpm

  • Maximum Stirring Capacity (approx):

    • F100: 100 mL

    • F250: 250 mL

    • F500: 500 mL

    • F1000: 1000 mL

    • F2000: 2000 mL

  • Max Stirring Bar Size: Depends on flask volume (commonly 10–40 mm)


Physical

  • Dimensions (approx):

    • F100: 165 × 135 × 70 mm

    • F250: 190 × 165 × 75 mm

    • F500: 215 × 185 × 80 mm

    • F1000: 250 × 220 × 90 mm

    • F2000: 300 × 260 × 100 mm

  • Net Weight (approx):

    • F100: 1.2 kg

    • F250: 1.5 kg

    • F500: 1.8 kg

    • F1000: 2.2 kg

    • F2000: 2.8 kg


Safety & Features

  • LCD digital temperature & speed readout

  • PID temperature control

  • Over-temperature automatic shutoff

  • Chemical-resistant coated body

  • Thermal insulation for user safety

  • Non-slip rubber feet

  • CE / ISO compliant (if applicable)

Datasheet

download
