Description
The Peltier?Cooled Incubator ILP?240 is a high?performance laboratory incubator that leverages thermoelectric Peltier technology to provide energy?efficient, vibration?free temperature control without traditional compressors or refrigerants. With a generous 240?L chamber, it delivers a stable and uniform thermal environment for biological samples, culture work, enzyme reactions, conditioning procedures, and other temperature?sensitive laboratory applications.
Operating across a temperature range from +5??C above ambient up to +70??C, the ILP?240 uses advanced Peltier thermoelectric modules to provide smooth, quiet cooling and heating. This makes it especially suitable for applications where mechanical vibration or noise could affect results ? for example, delicate culture incubation or sensitive material conditioning.
Temperature regulation and monitoring are managed through an intuitive microprocessor PID controller, allowing precise temperature settings and real?time display of actual versus set values. The interior workspace is equipped with stainless?steel wire shelves, which offer flexible sample arrangement and are easy to clean and maintain. Internal LED lighting ensures excellent visibility throughout the chamber for efficient sample handling and inspection.
Safety and usability are enhanced with features such as an open?door alarm that alerts users to unintended access or temperature deviations, and a secure door lock to protect valuable contents. External access ports allow integration with optional third?party sensors or monitoring devices, supporting enhanced data logging and compliance with quality standards.
Robust in design yet energy?efficient in operation, the ILP?240 is ideal for research laboratories, clinical facilities, quality control departments, and industrial R&D environments that require quiet, vibration?free, and precisely controlled incubation. Its combination of thermoelectric technology, intuitive controls, and dependable performance supports efficient workflows for both routine and specialized laboratory tasks.
Specifications
Peltier-Cooled Incubator ILP 240 Specifications
The ILP 240 is a large-capacity laboratory incubator utilizing Peltier modules for high-precision heating and cooling. This design ensures an environmentally friendly operation without refrigerants, offering a vibration-free environment that is critical for the growth of sensitive organisms and protein crystallization.
Â
Â
Technical Parameters
-
Chamber Capacity: 230 Liters
-
Working Capacity: 230 Liters
-
Air Convection: Forced
Â
-
Temperature Range: 0 to 70C (maximum 20C below ambient temperature)
Â
-
Temperature Resolution: 0.1C
-
Temperature Fluctuation at 37C: ±0.1C
-
Temperature Variation at 37C: ±0.3C
-
Temperature Protection: Class 2.0 (Smart) or Class 3.3 (Smart PRO) according to DIN 12880
Â
-
Controller: Microprocessor PID with 4.3 inch (Smart) or 7 inch (Smart PRO) touch screen
-
Nominal Power: 1000 W
-
Voltage: 230V 50/60 Hz
Physical and Material Data
-
Internal Dimensions (W x H x D): 560 x 760 x 540 mm
-
Overall Dimensions (W x H x D): 750 x 1070 x 870 mm
-
Internal Material: Acid-proof stainless steel (DIN 1.4301)
-
Housing Material: Powder-coated sheet or Stainless steel linen finish (IG models)
Â
-
Unit Weight: 125 kg
-
Shelves (Standard / Max): 3 / 10
Â
-
Max. Shelf Workload: 25 kg
-
Max. Unit Workload: 90 kg (120 kg for reinforced version)
Functional and Safety Features
-
Peltier Cooling System: Provides efficient, silent, and vibration-free temperature control, eliminating the maintenance associated with traditional compressors.
Â
-
Double Door Design: Features an outer solid door and an inner glass door to allow for sample viewing while maintaining temperature stability.
Â
-
Smart/Smart PRO Control: Allows for multi-segment time and temperature programming, data recording, and visual/audible alarms.
Â
-
Data Logging and Connectivity: Integrated USB and LAN ports for exporting data and event logs; Smart PRO includes Wi-Fi capabilities.
Â
-
Security: Multi-level user access control and password protection for program settings.
Â
-
Access Port: Includes a 30 mm diameter access port on the left side for external monitoring equipment.
Â
-
Safety Alarms: Visual and acoustic indicators for temperature deviations, door open status, and power interruptions.
