Drying Oven SLW 75

POL-EKO Laboratory Drying Oven SLW 75 The SLW 75 is a professional 75-liter forced-air laboratory drying oven designed for high-efficiency drying, thermal processing, and component testing. Featuring forced air convection and a temperature range of ambient +5?C to +300?C, it ensures rapid heat-up times and exceptional temperature stability throughout the chamber. Equipped with the Smart 4.3-inch color touchscreen (or the advanced 7-inch Smart PRO), it offers intuitive multi-segment programming, an “Alarm Bar” for visual status monitoring, and integrated data logging via USB/LAN. Its high-grade acid-proof stainless steel interior and robust safety features make it a reliable partner for pharmaceutical, medical, and industrial research.

SKU: SLW 75 Categories: , Brand: Product ID: 21665

Description

The POL-EKO SLW 75 is engineered for users who demand precision and speed. The Forced Air (W) system is the defining characteristic of this model. By utilizing a high-quality fan with adjustable speed (0?100%), the oven actively circulates air, eliminating the risk of thermal stratification. This results in superior temperature variation ($pm$2.0?C at 105?C) across all shelves, ensuring that whether a sample is placed at the top or bottom of the 75-liter chamber, it receives identical thermal treatment.Intelligence and Compliance:The SLW 75 is built to meet modern laboratory documentation standards:Controller Options: Choose between the Smart controller (4.3″ screen, 5 user programs) for standard daily tasks, or the Smart PRO (7″ screen, 40 programs) for complex, regulated workflows requiring Wi-Fi and 21 CFR Part 11 compliance.Data Integrity: All models include an internal memory that logs temperature data and events. This data is easily exported via USB or accessed via LAN, providing a complete audit trail for quality control.Safety Standards: Equipped with Class 2.0 (Smart) or Class 3.1 (Smart PRO) over-temperature protection according to DIN 12880, as well as a physical door lock and open-door alarm.Robust and Ergonomic Design:The interior is crafted from acid-proof stainless steel (DIN 1.4301), which is highly resistant to corrosive chemicals and easy to decontaminate. The unit features an adjustable $emptyset$40 mm air-flap to manage moisture exhaust and a $emptyset$30 mm access port for external validation probes. For heavy-duty industrial samples, a reinforced version (W) is available, doubling the unit’s total workload capacity from 40 kg to 80 kg.Primary Applications:General Drying: Rapid moisture removal from glassware, metal tools, and dense materials.Material Research: Curing of resins, thermal aging of plastics, and stability testing of electronic components.Biotechnology: Protein digestion and plant tissue drying where precise temperature control is vital.Food & Agriculture: Sample preparation and moisture analysis for standardized testing.

Specifications

Standard equipment SLW 75

  • temperature range + 5°C above ambient temperature … +300°C
  • chamber volume 108 liters
  • working capacity 73 liters
  • quality control protocol at +105°C
  • instruction manual in English and menu in various languages
  • over temperature protection 2.0 (Smart), 3.1 (Smart PRO) class according to DIN 12880
  • open door alarm
  • air-flap Ø40 mm
  • LAN port and USB port
  • access port to enter an external sensor (Ø30 mm) on the left side of the unit
  • door lock
  • Stainless steel wire shelf (INOX)
  • external full doors
  • Wi-Fi communication (only Smart PRO)
  • LAN cable (only Smart PRO)
  • LabDesk software for, inter alia, downloading data on computer (only Smart PRO, for Smart version – optional)
  • available controllers: Smart or Smart PRO
