Cooled Incubator ST 5

Short Description The POL-EKO ST 5 is a mid-to-large capacity 300-liter cooled incubator designed for high-throughput laboratory applications like BOD determination, microbiological research, and stable sample storage. Featuring a forced air convection system and a standard temperature range of +3?C to +40?C (expandable up to +70?C with the Smart PRO controller), it provides a 243-liter working capacity in an upright format. Equipped with a high-fidelity touch-screen controller and a robust stainless steel interior, it offers a reliable and secure “Perfect Environment” for intensive research and diagnostic workflows.

Description

The Cooled Incubator ST 5 is a professional-grade thermostatic solution engineered by POL-EKO to provide uncompromising temperature stability and uniformity for large sample batches. With a 300-liter chamber capacity, this model is a workhorse for laboratories performing BOD5 tests, seedling germination, pharmaceutical stability testing, and the controlled storage of chemical reagents or vaccines.

Superior Climate Control The unit utilizes a microprocessor-based PID controller and forced air convection with an adjustable fan speed (50-100% for ST models) to maintain a highly stable internal climate. While the standard Smart controller provides a range of +3?C to +40?C, the Smart PRO version extends this performance up to +70?C, making it suitable for specialized high-temperature incubation. The ST 5 also includes an automatic defrosting function and comprehensive alarms for temperature sensor failure and open doors.

Advanced User Interface The ST 5 is available with two sophisticated control options to suit different laboratory needs:

Smart Controller: Features a 4.3-inch color touch screen, memory for 5 user programs, and USB/LAN ports for straightforward data transfer.

Smart PRO Controller: A premium 7-inch color touch screen with Wi-Fi connectivity, multi-user management, and an alphanumeric keyboard for easy programming of up to 40 segments and 100 loops. Both controllers are designed for operation with gloves and feature a prominent Alarm Bar for immediate status awareness.

Built for Professional Use Constructed for long-term durability, the ST 5 features an interior made of stainless steel (DIN 1.4016) for Comfort models or acid-resistant stainless steel (DIN 1.4301) for Premium models. The unit comes standard with 4 stainless steel wire shelves (expandable to 7), a physical door lock, and a ?30 mm access port. For specialized photostability or growth studies, it can be equipped with the FOT photoperiodic system for day and night light simulation.

Datasheet

Specifications

Pol-Eko ST 5 (Cooled Incubator)
The ST 5 is a versatile, freestanding thermostatic cabinet with a 300-liter capacity. It is ideal for laboratories requiring more vertical storage space for BOD determination or sample incubation without a significantly larger footprint.

Chamber Capacity: 300 Liters

Working Capacity: 251 Liters

Air Convection: Forced

Temperature Range (Smart): +3 to +40°C (Optional: Up to +70°C)

Temperature Range (Smart PRO): +3 to +70°C

Temperature Resolution: 0.1°C

Temperature Fluctuation (at 37°C): +/- 0.3°C

Temperature Variation (at 37°C): +/- 0.6°C

Temperature Protection:

Smart: Class 1.0 (Standard) / Class 3.3 (Optional)

Smart PRO: Class 3.3 (Standard)

Internal Dimensions (W x H x D): 480 x 1260 x 420 mm

External Dimensions (W x H x D): 600 x 1520 x 650 mm

Shelves (Standard / Max): 4 / 7

Max Shelf Workload: 10 kg

Max Unit Workload: 60 kg

Controller: Smart (4.3″ touch screen) or Smart PRO (7″ touch screen)

Connectivity:

Smart: LAN, USB

Smart PRO: Wi-Fi, LAN, USB

Interior Material:

Comfort (C): Stainless steel (DIN 1.4016)

Premium (P): Acid-proof stainless steel (DIN 1.4301)

Voltage: 230V 50-60Hz

Nominal Power: 350 W

Refrigerant: R1234ze (GWP=1)

Net Weight: 91 kg

Standard Equipment: Internal LED light, Ø30 mm access port, door lock, open door alarm.
