Cooled Incubator ST 2

The POL-EKO ST 2 is a mid-sized 150-liter cooled incubator designed for reliable BOD determination, stability testing, and microbiological incubation. Featuring a forced air convection system and a temperature range of +3?C to +40?C (expandable to +70?C with the Smart PRO controller), it offers a 122-liter working capacity in a space-efficient upright design. Equipped with an intuitive color touch-screen controller and a robust stainless steel interior, it provides a stable and secure environment for a wide variety of laboratory applications.

Description

The Cooled Incubator ST 2 is a professional-grade thermostatic solution from POL-EKO, engineered to maintain precise temperature conditions regardless of ambient laboratory fluctuations. With its 150-liter chamber capacity, the ST 2 is a popular choice for laboratories performing BOD5 tests, seedling germination, and the storage of chemical reagents or vaccines.

Temperature Stability & ControlThe unit features a microprocessor-based PID controller and forced air convection with adjustable fan speeds to ensure rapid temperature recovery and high uniformity throughout the chamber. While the standard Smart controller provides a range of +3?C to +40?C, upgrading to the Smart PRO controller extends the maximum temperature to +70?C. The ST 2 also includes an automatic defrosting function and comprehensive alarms for temperature sensor failure and open doors.

User-Friendly InterfaceDepending on your laboratory’s data management requirements, the ST 2 is available with two controller options:

Smart Controller: Features a 4.3-inch color touch screen, memory for 5 user programs, and USB/LAN ports for data transfer.

Smart PRO Controller: Offers a larger 7-inch color touch screen, Wi-Fi connectivity, and advanced administrative functions with multi-level user access and 40-segment programming.Both interfaces are designed for operation with gloves and include a quick-status “Alarm Bar.”

Quality ConstructionThe ST 2 is built for durability, featuring an interior made of stainless steel (DIN 1.4016) for the Comfort model or acid-resistant stainless steel (DIN 1.4301) for the Premium model. Standard equipment includes 3 stainless steel wire shelves (expandable to 4), a physical door lock, and a ?30 mm access port for external monitoring equipment.

Datasheet

Specifications

Pol-Eko ST 2 (Cooled Incubator)

The ST 2 is a versatile, mid-sized thermostatic cabinet frequently used for BOD determination, seed germination, and wine/beverage storage. It is available with either the Smart or Smart PRO controller.


  • Chamber Capacity: 150 Liters


  • Working Capacity: 122 Liters


  • Air Convection: Forced

  • Temperature Range (Smart): +3 to +40°C (Optional: +3 to +70°C)


  • Temperature Range (Smart PRO): +3 to +70°C


  • Temperature Resolution: 0.1°C

  • Temperature Fluctuation (at 37°C): +/- 0.3°C

  • Temperature Variation (at 37°C): +/- 0.6°C

  • Temperature Protection:

    • Smart: Class 1.0 (Standard) / Class 3.3 (Optional)

    • Smart PRO: Class 3.3 (Standard)

  • Internal Dimensions (W x H x D): 480 x 660 x 420 mm

  • External Dimensions (W x H x D): 600 x 860 x 650 mm

  • Shelves (Standard / Max): 3 / 4

  • Max Shelf Workload: 10 kg

  • Max Unit Workload: 30 kg

  • Controller: Smart (4.3″ touch screen) or Smart PRO (7″ touch screen)


  • Connectivity:

    • Smart: LAN, USB


    • Smart PRO: Wi-Fi, LAN, USB


  • Interior Material:

    • Comfort (C): Stainless steel (DIN 1.4016)


    • Premium (P): Acid-proof stainless steel (DIN 1.4301)


  • Housing: Powder-coated sheet (Standard) or Stainless steel linen finish (IG version)


  • Voltage: 230V 50-60Hz

  • Nominal Power: 250 W

  • Refrigerant: R1234ze (GWP=1)

  • Net Weight: 54 kg

  • Standard Accessories: Internal LED light, Ø30 mm access port, door lock, open door alarm.
