Cooled Incubator (IL) ILW 400

Short Description The POL-EKO ILW 400 is a professional 424-liter cooled incubator designed for high-capacity microbiological research, BOD determination, and stable sample storage. This large-volume unit features a forced air convection system for rapid temperature recovery and exceptional uniformity across the chamber. Operating with a standard temperature range of 0?C to +70?C (expandable up to +100?C with the Smart PRO controller), it provides a robust and reliable “Perfect Environment” for demanding laboratory environments.

Description

The Cooled Incubator (IL) ILW 400 is a high-performance thermostatic chamber engineered by POL-EKO to meet the needs of laboratories requiring significant storage space without compromising on precision. With its 424-liter capacity, this unit is perfectly suited for large-scale microorganism breeding, plant growth simulation, and complex physicochemical analyses.

The chamber is equipped with a forced air circulation system that ensures consistent temperature distribution, even when the incubator is fully loaded. While the standard range is 0?C to +70?C, users can opt for specialized versions that extend performance down to -10?C or up to +100?C (available with the Smart PRO controller). The system also features an automatic defrosting function to maintain peak performance during long-term cooling cycles.
+1

Customization is available through two advanced control interfaces:

Smart Controller: An intuitive 4.3-inch color touch screen that supports 5 user programs and features LAN/USB ports for data management.

Smart PRO Controller: A premium 7-inch color touch screen with Wi-Fi connectivity, multi-user management, and 40 programmable segments for sophisticated time-temperature profiling.

Built for durability, the ILW 400 features an acid-resistant stainless steel (DIN 1.4301) interior and a double-door configuration?a solid external door for insulation and a glass internal door for sample observation. For maximum security, the unit includes an open-door alarm, a physical door lock, and over-temperature protection (Class 2.0 or 3.3).

Datasheet

Specifications

Pol-Eko ILW 400 (Cooled Incubator)

  • Chamber Capacity: 424 Liters

  • Working Capacity: 424 Liters

  • Air Convection: Forced

  • Temperature Range (Smart): 0 to +70°C (Optional: -10 to +70°C)

  • Temperature Range (Smart PRO): 0 to +100°C (Optional: -10 to +100°C)

  • Temperature Resolution: 0.1°C

  • Temperature Fluctuation (at 37°C): +/- 0.2°C

  • Temperature Variation (at 37°C): +/- 0.3°C

  • Temperature Protection (Smart): Class 2.0 (DIN 12880) / Class 3.3 (Optional)

  • Temperature Protection (Smart PRO): Class 3.3 (DIN 12880)

  • Internal Dimensions (W x H x D): 800 x 1040 x 510 mm

  • External Dimensions (W x H x D): 1020 x 1720 x 780 mm

  • Shelves (Standard / Max): 3 / 14

  • Max Shelf Workload: 25 kg (Standard) / 100 kg (Reinforced PW version)

  • Max Unit Workload: 120 kg (Standard) / 300 kg (Reinforced W version)

  • Controller: Smart (4.3″ touch screen) or Smart PRO (7″ touch screen)

  • Connectivity (Smart): LAN, USB (Data log recording)

  • Connectivity (Smart PRO): Wi-Fi, LAN, USB (Data/Event logs & program upload)

  • Interior Material: Acid-proof stainless steel (DIN 1.4301)

  • Housing: Powder-coated sheet (Standard) or Stainless steel linen finish (IG version)

  • Door Type: Double doors (solid external with lock, glass internal)

  • Voltage: 230V 50-60Hz

  • Nominal Power: 1300 W

  • Refrigerant: R290 (GWP=3)

  • Net Weight: 185 kg

  • Standard Accessories: Ø30 mm access port (left side), open door alarm, door lock, castors, LabDesk software (Smart PRO).
